| What We Race |
|
RG-65 - Developmental The RG-65 is an International development class with a 30 year history. The class rules limit only the length of the hull (65 cm), the height of the rig (110 cm) and the sail area (2250 square centimeters) 650mm long.
The RG65 is an international development class with a 50 year history. The class rules limit only the length of the hull (65 cm/25.6 in), the height of the rig (110 cm/43.3 in) and the sail area (2250 square centimeters/348.8 sq in.). The class originated in Argentina as a free-sailing class and is one of the fastest growing radio sailing classes in the world. Boats are light, quick, and responsive. A typical boat weighs 1 kilogram with a 500 gram bulb. Many designs can be found on the internet and kits and fittings are readily available. Boats can be easily transported in the smallest of cars and sailed in small, urban ponds as well as open water. Class Website | ||||||||
|
Soling 1 Meter - One Design Sanctioned in 1993. The Soling 1 Meter is based on the full-size Olympic Soling.
Specifications: 39.37" long, 8-5/8" beam, approx. 60" bottom keel to tip of mast. 10 lbs. min.
Features: Performance; Single rig allowed means lower total cost; One Design for equality of boats; Kit-Based, kits Available from two manufacturers; Wide distribution of local clubs in all AMYA Regions. The Soling 1 Meter Class was first sanctioned by the AMYA in 1993. With thousands of kits sold, and some 4000 boats registered, you can find a Club sailing the Soling 1 Meter in ALL 8 AMYA Regions, and three Provinces in Canada. Over 70 USA and Canadian Clubs list the Soling 1 Meter as the one or the only boat that they support. Something like 50% of ALL RC sailors own at least one Soling!! For over thirty years since being AMYA-sanctioned, the "Soling" has been a Class that offered top competition at the local, Regional, and USA as well as Canadian National Championship levels.
Class RulesThe Soling 1 Meter is a true One-Design: All aspects related to performance are intended to be restricted to what can be achieved by building a Kit straight from the manufacturer's instructions. (The Soling 1 Meter Class Rules may be downloaded from the links table on this page.) Performance: Soling 1 Meters point high, sail fast, and resist "submarining" like some other more narrow and lighter boats. On a fresh reach or run, the boat gives her skipper fully controlled, exhilarating performance. The fin keel draws only about 8" of water, so the Soling 1 Meter is easier to carry and transport, and can be launched from a shore without wading, as well as from a dock. And, the Soling resists snagging in pond weeds - she can almost always be sailed back to shore, instead of having to be rescued by rowboat. Low total cost: Unlike many RC boats, Soling 1 Meter Class allows one rig, using lower cost flat-paneled polyester sails. The Soling can be sailed in winds from near zero to over 20 MPH, using that single rig. And, in a regatta of less than 5 days' duration, you must use the same rig throughout the regatta. This saves hundreds of dollars for additional rigs and sails required to be bought in order to compete in most other popular designs. Soling 1 Meters must be built from a kit available from the original manufacturer- Victor Model Products (out of business as of 2018), AND currently only from one of two Class-approved manufacturers: 3DRC Boats offers Almost ready to Sail kits that can be finished in about 12 hours by virtually anyone. 3DRC also sells full rig kits, aluminum mast and booms, with or without major brand sails. Vac-U- Boats offers an unassembled hull kit. You cannot modify the interior construction of the 3DRC or Vac-U-Boat kits, such as removing structure, or adding carbon fiber or other "exotic" materials. Made in the USA: All Solings, since the first off the mold, have been made in the USA. To buy a NEW Soling, contact one or both of our manufacturers: 3RC Boats TM sales@3drcboats.com Doug Rieger 1-440-610-9542 http://3drcboats.com OR Vac-U-BoatTM philpace@vac-u-boat.com Phil Pace 1259 Humphries Rd. Conyers, GA 30012 http://www.vac-u-boat.com/ Class Website | ||||||||
|
Soling 50 M - One Design The Soling 50 is based on the full-size Olympic Soling. This medium-sized yacht's hull must be initially purchased from a manufacturer (See Class Page). Decks, keels, rigging, spars and sails are strictly controlled, but may be purchased or made from scratch. Almost all other equipment is up to the owner. 50" long.
The Soling 50 Class is a small-scale version (50 inches long) of the Olympic Soling three-person, 27 foot, 3 man, keelboat, sailed worldwide and also in the Olympic games since 1967. The original boat was designed by Jan Herman Linge of Oslo, Norway in 1964. The name "Soling" was a word coined by Linge. In 1970, John & Laurie Converse, owners of Vortex Model Engineering saw a full sized Soling and developed and manufactured the radio-controlled model sailboat. It started out as the Soling M Class (Marblehead) and in 1972 it dominated the Marblehead Class ACCR 50/800 class. By 1975 the fleet grew into it's own class, called the Soling O/D (One Design) and it's logo the Greek letter 'Omega' was authorized by the original designer Jan Linge. Today, the Soling 50 is one of 27 different classes and sizes of sailboats sanctioned by the national American Model Yacht Association and has very active fleets racing in California, Florida, Michigan and Texas and has individual boats scattered all over the U.S. The Soling 50 hulls are identical to the original Vortex hulls and are currently available from three (3) different suppliers in the U.S. The Soling 50 Class is an AMYA one-design class boat. It is a great starter boat, easily transported with detachable sail rig weighing a minimum of 17 lbs. Radio equipment is an inexpensive 2 or 3 channel surface radio. The Soling 50 Class offers close and competitive sailing in moderate and stiff winds. It acts and feels closer to a full-sized boat than most other R/C model yachts. | ||||||||
|
Star 45 - One Design Based on the full-sized Star Class of Olympic and International fame. Builders are allowed variability in materials but dimensions are closely controlled. 45" long.
The Star 45 is a 45" long hard chine hull; semi-scale model of the full-size Olympic Star. Weighing in from 12 to 13 pounds, carrying about 1000 square inches of sail area, with a ballast to weight ratio approaching 70%, Star 45's are very fast and super responsive. Few model yachts, if any, can equal their speed and agility. With the ability to turn in a little more than a boat length, when properly trimmed, the boat can be easily sailed hands off for the length of the pond. Skippers have the option of completely scratch building the boat from wood or fiberglass using plans available from the AMYA , purchasing laser cut frames based on those plans or obtaining fiberglass major components available from Class approved suppliers. Depending on the approach taken, a boat can be completed, ready to race, from between $500 to $1500. The Star 45 is a one design class, but some latitude is allowed with the shapes and locations of the underwater surfaces, rig construction and sail area. Multiple rigs, however, are not needed for heavy air sailing given the high ballast to weight ratio and stable hull form. The fun factor of building and sailing a Star 45 is very high and, like the full sized boat, were made to race. You are invited to join in. You can register or transfer a boat online via the link on this page, or if you prefer the paper form, you can find either method on the Star 45 Class website at star45class.com Class Website | ||||||||
|
US One Meter - Developmental The U.S. One Meter is a small-sized development class yacht, with an appearance similar to the International One Metre yachts. This development class is restricted in overall length, sail area and several other minor measurements. The U.S. One Meter is surprisingly fast and seaworthy for its size. 39.37" long, 600 sq. inches of measured sail area with about 50 sq inches of "free area".
The One Meter yacht is lightweight, very fast and responsive to the controls making it a fun boat to sail, either as a pond boat or in competition.
Class RulesAn inexpensive two channel radio is all that is required for control of sails and rudder. The boat is easily disassembled and fits in a small size automobile for transporting to the pond or lake. The U.S. One Meter class is one of the least expensive classes for the new skipper just starting in the hobby of R.C. sailing due to its "build it yourself" nature, . The U.S. One Meter Class is a developmental class, which means there are very few design restrictions. They include, overall hull length, keel depth and sail area (see class specification for the few remaining restrictions). The generally unrestrictive nature of the specifications, encourages one of a kind Home Built yachts. The hull can be self designed or built from available free plans. It is easily planked from wood, or can be made from wood forms covered with fiberglass, carbon fiber or Kevlar. The structure of the class specifications allows the designer/builder to experiment with a design, and then try it out on the water. It is a true "designers class". Class Website | ||||||||
|
Victoria - One Design Sanctioned in 1997. Low cost, ARS kit from Thunder Tiger modeled after the America's Cup yachts from the 1990's.
30.7" long, 433 sq in sail area, 4.5 lbs displacement.
The Victoria One Design is a simple, affordable, sailboat manufactured by the Thunder Tiger Model Company, and distributed world wide. The kit's low cost (about $150 for the kit, $250 to perhaps $400 ready to race), ease of assembly, and good sailing characteristics make it a great first yacht, while remaining fun to sail and race for old hands as well. It is easy to transport, fully rigged, in the smallest of cars. The emphasis of the Victoria is on SIMPLICITY and FUN, and to these ends check out the Victoria Class Information Center for the latest building, tuning, and sailing tips, along with other interesting and useful information about the boat.
Class RulesThe boat itself is made of ABS plastic, and is quite durable, capable of surviving virtually any mishap or collision. The kit also includes high quality aluminum spars, sails, and all necessary fittings. All you need to do is add a two-channel radio, two servos and you're ready to sail. Construction is generally a weekend project. The ease of assembly also makes the Victoria a great "club" boat, as new skippers can buy a boat and join the racing with a minimum of trouble and expense. Many clubs conduct "Silver Fleet" racing consisting of boats made entirely from all kit parts. | ||||||||
